Precision Checking Inspection Fixture

Description

Precision checking and inspection fixture for verifying part geometry against design intent. Portable baseplate with locating supports and clamps for production quality control. Supports automotive stamping and assembly verification workflows. Produced with CNC and conventional machining capability plus Faro laser/arm metrology.

Key attributes

Type

Checking fixture

Use

Dimensional inspection

Feature

Portable base with handles
